| Embata hamata: whirling specimen; dorsoventral view. (1). |
| |
 |
| Embata hamata: whirling specimen; dorsoventral view. (1). |
| |
 |
| Embata hamata: same specimen; it seems as if the trochal discs are flexible and can be twisted somehow. (1). |
| |
 |
| Embata hamata: creeping specimen; retracted corona, dorsoventral view. (3). |
| |
 |
| Embata hamata; left: head / corona of whirling specimen from (1); right: rostrum of of head, corona retracted (crop of the above image) (3). |
| |
 |
 |
| Embata hamata: lateral view of optical longitudinal section, focus plane on the dorsal antenna. (1). |
| |
  |
| Embata hamata: two aspects of the foot with characteristic divergent spurs, ventral view. . Left: all 4 toes are retracted; right: the dorsal toes are expanded. (2). |
| |
 |
| Embata hamata: ramate trophi with dental formula (DF): 2/2; rami length: 17µm |
| |
 |
| Embata hamata: specimen with retracted corona; focal plane on the foot with characteristic spurs and 4 toes. (4) |
| |
| |
| |
| |
| |
|
Location (1): Le Garo; Ploguin; Brittany, France |
 |
| |
| Habitat: moss in lotic water (click to enlarge >>>>) |
| |
| Date: 24.08.2021 (1); |
| |
|
|
|
|
|
|
|
| |
| |
| |
|
Location (2) (3): Stang-Alar; Botanical Garden, Brest; Brittany, France |
 |
| |
| Habitat (2) (3): detritus/ psammon in lotic water (click to enlarge >>>>) |
| |
| Date: 28.08.2021 (2); 16.08.2021 (3) |
| |
|
|
|
|
|
| |
| |
|
Location (4): Im Mailand, Bochum near Kemnader See, NRW, Germany |
 |
| |
| Habitat(4): sediment in lotic water (click to enlarge >>>>) |
| |
| Date : 20.12.2023 (4) |
| |
|
|
|
|
|
| |
| |
| |
